The TENKILOMETERS high quality HS8145C Single Band XPON ONU ONT is High-performance forwarding capabilities, it guarantees an exceptional user experience for VoIP, Internet, and HD video services. This is the ideal terminal solution, providing future-ready service support for FTTH deployments.
|
Technical items |
Descriptions |
|
Out Port contains |
1GE+3FE+1POT+1UB+WiFi |
|
WIFI signal |
2.4G WiFi |
|
Wireless gain |
2db |
|
USB |
2.0 |
|
LAN |
1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface |
|
TEL |
H248/SIP Voice Protocol |
|
PPPOE BRIDGE |
Support |
|
Firmware |
English |
|
Dimension/weight |
153mm*125mm*32mm/176g |
|
Fiber port |
1 GPON /EPON interface, ingle-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps |
|
Wavelength |
Tx 1310nm, Rx 1490nm |
|
Fiber interface |
SC/UPC /APC Singal mode |
|
RX sensitivity |
>-28dBm (1490nm) |
|
DC power |
12V 1A, external AC-DC power adapter |
|
Button |
Reset,Power,Wlan, Wps |
|
Operation |
Working temperature: -5- +55℃ working humidity:10-90%(non-condensation) |
|
Storage |
Storage temperature: -30℃- +60℃ storage humidity: 10-90%(non-condensation) |
1. Plug-and-Play: Easily deploy services with a single click on the NMS, eliminating the need for on-site configuration.
2. Remote Diagnosis: Remote fault detection through loop-line testing of POTS ports, call emulation, and PPPoE dial-up emulation.
3. Link Monitoring: Achieve end-to-end link detection with 802.1ag Ethernet OAM, ensuring network stability.
4. High-Speed Forwarding: Experience 900 Mbit/s forwarding in NAT scenarios, ensuring swift data transmission.
5. IPv6 Capability: Supports IPv6/IPv4 dual stack and DS-Lite, ensuring compatibility with modern networking standards.
